Dover HEIL DuraPack 5000 - Tailgte Lower;Raise Flow Diagram

701-8426-2
= PUMP PRESSURE
= RETURN PRESSURE
LEGEND
TAILGATE RAISETAILGATE LOWER
= INTERMEDIATE PRESSURE
FROM
VALVE
ADJACENT
SECTION
UNDERBODY VALVE
ADJACENT
VALVE
SECTION
FROM
TO
TANK
TANK
TO
UNDERBODY VALVE
CYLINDERS
TAILGATETAILGATE
CYLINDERS
