Dover HEIL DuraPack 5000 - Reeving Cylinder Raise (during Blade Down);Lowering (during Blade Up) Flow Diagram

701-8426-7
= PUMP PRESSURE
= RETURN PRESSURE
LEGEND
REEVING CYLINDER RAISING CONTAINER
CYLINDERS
REEVING
LOWER PANEL UPPER PANEL
CYLINDERSCYLINDER
REGEN.
VALVE
TANK
TOUNDERBODY
VALVE
TAILGATE VALVE
FROM
CYLINDER
REEVING
CYLINDERS
LOWER PANEL UPPER PANEL
CYLINDERS
VALVE
REGEN.
TANK
TO
VALVE
FROM
UNDERBODY
TAILGATE VALVE
DURING BLADE DOWN
REEVING CYLINDER LOWERING CONTAINER
DURING BLADE UP
