Program 109-0201 Rear Loader Pack On The Fly
109-0201.doc Revision - 12/19/08
Page 1 of 3
PURPOSE
The purpose of this document is to detail the operation of the Pack on the Fly Programable Logic Controller for rear
loaders.
Revision History
REVISION DATE DESCRIPTION
Initial 12/19/08 Initial Release of documentation
1.01 OUTPUT CHART
Chart below shows PLC output and functions.
OUTPUTS
POWERED
EOS FUNCTION
10.01 Pump #1
10.03 Pump #2
10.05 Not Used
10.07 Not Used
Display only outputs (i.e. not connected to the “real world”.)
OUTPUTS
NON-
POWERED
FUNCTION
10.00 Not Used
10.02 Engine Speed Fault
10.04 Not Used
10.06 Calibration Set Indicator
1.02 INPUT CHART
Chart below shows PLC input and functions.
INPUTS
POWERED
EOS FUNCTION
0.00 Alternator Input
0.01 Tach Calibration Input #1
0.02 Tach Calibration Input #2
0.03 Not used
0.04 High Flow Request
0.05 Low Torque Pressure Switch
0.06 Not used
0.07 Not used
2.0 Inputs
• 0.00 Alternator “R” Stator
- This Input monitors the Engine Speed via the Alternator R Stator Pulse. The R
Stator Pulse typically is a –1.4-volt minimum to +15 volt maximum square wave of which the frequency varies
relative to engine speed. The engine RPM is determined by counting the pulses of the Square wave and scaling
ratio to engine speed. The alternator signal voltage should read 6.5 – 7 volts at the 0.00 input terminal with a
digital volt ohmmeter.
