Dräger P3U - Submenu Instrument

53
The menu » Information «
Submenu » Instrument «
The submenu » Instrument Info « contains all functions for interrogating the unit status.
Warnings
— This function displays any existing warnings in clear text with the warning number,
see page 47.
The icon » « is displayed if any warnings are active.
● Select the menu items » Information «, » Instrument « and » Warnings « in this or-
der, pressing the » « key after each selection.
— Any existing warnings are displayed in clear text.
If more than one warning exists, the number of the currently displayed warning
and the total number of warnings are displayed in the top right corner
(example: 1/3 = screen 1 of 3).
Faults
— This function displays any existing faults in clear text with the error number, see
page 46.
If a fault code exists, the icon » « is displayed.
● Select the menu items » Information «, » Instrument « and » Faults « in this order,
pressing the » « key after each selection.
— Any existing faults are displayed in clear text.
I
f more than one fault exists, the number of the currently displayed fault and the total
number of faults are displayed in the top right corner (example: 1/2 = screen 1 of 2).
Fault codes
— This function displays any existing faults / warning codes in the form of a table.
If a fault code exists, the icon » « is displayed.
● Select the menu items » Information «, » Instrument « and » Fault codes « in this or-
der, pressing the » « key after each selection.
— Any existing faults are displayed in the form of numerical codes in a table. If all nu-
merical groups are displayed with the value » 00 «, no faults exist.
Modules
— All installed hardware modules are displayed.
● Select the menu items » Information «, » Instrument « and » Modules « in this or-
der, pressing the » « key after each selection.
— A list of all possible modules is displayed. The installed modules are indicated by
a » «. Modules which are not installed are marked with a » «.
● Use the » « and » « keys to select individual modules and press the » «
key to display more detailed information.
