Drobo 5D3 - Viewing Storage Usage

Drobo 5D3 User Guide 91
● Total – The total available protected capacity.
● Used Space – The part of the total protected capacity that is currently being
used for data storage.
● Free Space – The part of the total protected capacity available for use.
Tip:
To view this information for other connected Drobo devices (if applicable), you
can click the up or down arrow key that displays to the left of the Drobo device
name, which is in the upper-left corner of the page. See the arrows in the image
below.
8.1.2 Viewing Storage Usage
The Storage Usage view of the Capacity page displays a capacity breakdown bar, which
provides more detailed information about how your drive space is being used on the
Drobo 5D3.
To view the storage usage:
1. In Drobo Dashboard on the All Drobos page, select the Drobo device whose storage
usage you would like to view, and click the Capacity option on the Navigation menu. The
Capacity page for that Drobo device opens.
