SYSTEM AREA
SYSTEM OPTIONS
KEYPAD TOG OP T/KYPD LOCKOUT OP T/SYSTEM TIMES
KYPD LOCKOUT OPT
(2)
Keypad Lockout Options
Keypad Lockout Options
This section contains programming for the keypad lockout feature. After a programmed number
of incorrect attempts to enter an access or installer’s code the keypad will lockout, preventing the
user from performing any function. A message “Keypad Lockout is Active” will be displayed for
the lockout duration. See “KYPD LOCKOUT” under “PAR TOGGLES” to enable the keypad
lockout feature on a partition.
Enter the number of incorrect code entries (from 000 to 255) required to activate keypad lockout
if the option is enabled. See “PAR TOGGLES”, “KYPD LOCKOUT” to enable the keypad lockout
feature on a partition. The default setting is 005.
This section determines the number of minutes the keypad lockout will remain active for. Enter the
duration of the keypad lockout. Valid entries are from 000 to 255. The default setting is 015.
System Times
They are system times relevant to the whole system.
The zone loop response time is the length of time (005 - 255 x 100 ms) a zone must be violated
before it is detected. (100 ms = one tenth of a second.) Minimum zone loop response time is 500
ms. The factory default setting is 005 (500 ms).
Program the amount of time (from 000 to 255 minutes) the bell output will activate when an alarm occurs.
The factory default setting is 004 (4 minutes). Bell Cutoff is for any output (Bell, SW Aux or PGM) that is
programmed for Fire and Burg, Inv Fire and Burg, Burg Only, Inv Burg Only, Fire Only, and Inv Fire Only.
Program the amount of time (000 - 255 Minutes) before a Police Code Alarm reporting code will
be sent to the monitoring station. A Police Code Alarm is sent when 2 zone alarms occur within
the programmed time. Default is 060 minutes.
Whenever a keypad is loaned to another partition, the keypad will return to it’s home partition
after the programmed amount of time. (000 - 255 seconds) default = 20 seconds.
Zone Supervision
The zone is a normally closed loop to ground. The zone will be violated when it is open.
All zones must have a 5600 ohm resistor across them. If the zone is shorted or open, it will be in a
violated condition. If the zone is open and programmed as a fire zone, it will be in a trouble
condition. See “[Q][2] Trouble Display”.
Notes: If zones are programmed for Fire or Links Supervisory, EOL resistors must be used.
This configuration will allow the panel to detect zone Faults (zone shorted), zone tampers (open
circuit), open zones (Alarm condition of the 11200 Ohms) and restored zones. If the zone is
disarmed and placed in the Tamper (open) or Fault (Short) state the keypad buzzer will sound
from all partition keypads (that the zone belongs to) for the length of bell time out or until an
access code is entered. A zone tamper (or Fault) alarm reporting code will be sent to the
monitoring station if programmed. When the partition is armed and a zone is Tampered or Faulted
all burglary outputs for the partition will activate for the length of bell time out or a valid access
code is entered. There will be no buzzer sounded while the zone is armed. A zone tamper (or
Fault) alarm reporting code and zone alarm reporting code will be sent to the monitoring station if
programmed. See Reporting Codes for details. Refer to the System Manual for detail on the
hookup procedure. All zones on the PC4010 can use double EOL resistors, except wireless
zones (Zone that belong to the PC4164), Fire Zones all types (Standard Fire, Delay Fire, Auto
Verify Fire, Sprinkler PC4700 2 Wire Smoke and Waterflow), Links Supervisory, Links Answer and
Forced Answer zones. These zone types must only be used with single EOL. double EOL
resistors allow the zone to be capable of detecting zone tampers and zone faults. The Tamper
resistor (5600 Ohms) is placed across the alarm contact, and the single EOL resistor (5600
Ohms) is placed between the alarm contact and the tamper contact.
TOTAL BAD CODES
(0)
LOCKOUT DURATION
(1)
SYSTEM TIMES
(3)
ZONE RESPONSE
(0)
BELL CUTOFF
(1)
POLICE CODE TIME
(2)
ZONE SUPERVISION
(4)
NO EOL
SINGLE EOL
DOUBLE EOL
KEYPAD TIMEOUT
(3)
