13
SYSTEM AREA
DLS SECTION
DLS TOGGLE S/DLS OPTION S/DLS REPORT CODES
DOWNLOAD
SECTION
This section will allow you to program all options related to downloading.
Download Toggles
Downloading Toggle Options. Toggle options are in the form of questions. Use the [Q] key to
toggle between Yes and No to enable or disable the feature. Use the [<][>] keys to scroll through
the options.
Downloading Enable?
YES = The panel will answer after the programmed number of rings.
NO = DLS Enable disabled. The only way downloading can occur is by using either the
“USER CALL UP” feature or the “PERIODIC CALLUP” feature. DLS Enable can be
turned on by the end user for 60 minutes if the “USER ENABLE DLS” option is enabled.
User Call Up?
YES = The user can cause the panel to call a remote computer by entering the [Q][6][Master
Code][7] user callup command. (See also “PHONE NUMBER” and “PANEL ID CODE” in
the DLS options.)
NO = The feature is disabled.
Double Call?
YES = If the panel detects 1 or 2 rings on the first call and then is called again within a variable
time of 000 to 255 seconds (programmable - see “2 CALL TIMER”), the panel will
answer the second call on the first ring. This is useful for bypassing an answering
machine on the same line as the panel.
NO = The panel will only answer after the programmed number of rings is reached. See “# OF
RINGS”.
Downloading Call Back?
YES = Callback is enabled. After connection to the panel both the computer and the panel will
hang up. The computer will then wait for the panel to call. If there is more than one
downloading computer, callback should be disabled.
NO = Callback is disabled. The downloading computer will have immediate access to the
control panel once accepted as valid.
Periodic Downloading?
YES = Periodic Downloading is enabled. Periodic downloading is used to allow the computer
to execute batch files. The computer must be waiting for a call for this feature to be
useable. See “Periodic Callup” for programming the time of day and the number of
days in between periodic downloads.
NO = Periodic Downloading disabled.
User Enables Downloading?
YES = The end user may enable ring detect for 60 minutes to allow a computer to access the
control panel. If the “DLS ENABLE” option has been enabled, this option is overridden.
NO = Option disabled.
DLS SECTION
(03)
DLS TOGGLES
(0)
DLS ENABLE
N
USER CALL UP
N
DOUBLE CALL
N
DLS CALLBACK
N
PERIODIC DLS
N
USER ENABS DLS
Y
To Next Page
