4.2.1 STATUS
This is the ‘home’ page, which is displayed when no other page has been selected, and the page that
is automatically displayed after a period of inactivity (LCD Page Timer) of the module control buttons.
Contains summary information of both supplies along with different module status display.
• Main Summary (Backup source)
• Main Summary (Primary source)
• Source supply summary
• Supervisors summary
• Monitors summary
This page changes with the action of the controller, when S1 is on load, S1 parameters are seen and
when changing to S2 on load, the S2 parameters are shown.
No Start Request
Example of the first status screen showing no start request to S2 and
S1 closed supplying the load…
S1 Closed
L-N 230V 40A
L-L 400V 50.0Hz
S2 Available
… and showing S2 on load.
S2 Closed
L-N 229V 40A
L-L 399V 50.1Hz
Press to access more status information about two supplies.
To Next Page
