9 MAINTENANCE, SPARES, REPAIR AND SERVICING
The controller is Fit and Forget. As such, there are no user serviceable parts within the controller.
In the case of malfunction, contact the original equipment manufacturer (OEM).
9.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE
If additional plugs are required from DSE, please contact our sales department using the part numbers below.
9.1.1 PACK OF PLUGS
Module type Plug Pack Part Number
DSE335 100-400-35
9.1.2 INDIVIDUAL PLUGS
Module Terminal Designation Plug Description Part No.
1-8
8 way 5.08 mm 007-164
9-17
9 way 5.08 mm 007-167
18-24
7 way 5.08 mm 007-447
25-29
5 way 7.62 mm 007-473
30-37
S2
8 way 7.62 mm 007-454
38-41
S1
4 way 7.62 mm 007-171
42-47
6 way 5.08 mm 007-446
48-53
6 way 7.62 mm 007-162
RS485
3 way 5.08 mm 007-174
NOTE: Terminals 24 and 27 are fitted to controllers but must not be connected.
9.2 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE
Item Description Part No.
Module fixing clips (packet of 4) 020-294
9.3 PURCHASING ADDITIONAL SEALING GASKET FROM DSE
Item Description Part No.
Module silicon sealing gasket 020-507
