DSE 335 - 4 DESCRIPTION OF CONTROLS; 4.2.9 SCHEDULER; 4.2.10 ABOUT

Description of Controls
057-233 ISSUE: 1 Page 56 of 90
4.2.9 SCHEDULER
Contains the current schedule plan for S2 configured in module.
2/3 Schedule 10:39
Example of the 3
rd
scheduled operation in bank 2 for S2.
Off Load Week 3
On 12:00 Run Time 00:30
M
MM
M T W T F S S
T W T F S ST W T F S S
T W T F S S
4.2.10 ABOUT
Contains important information about the module and the firmware versions. This information may be
asked for when contacting DSE Technical Support Department for advice.
About
Variant
335
Application
V3.0.20
USB ID
BC614E
Press to access more information about the module.
About
Bootloader V1.3.4
Analogue V2.0.0
•
Variant – 335
• Application Version – The version of the module’s main
firmware file (Updatable using the Firmware Update
Wizard in the DSE Configuration Suite Software).
• USB ID – Unique identifier for PC USB connection
•
Bootloader - Firmware Update bootloader software
version
•
