Description of Controls
Page 61 of 90 057-233 ISSUE: 1
4.7 STOP/RESET
NOTE: If a digital input configured to Panel Lock is active, changing module modes is not
possible. Viewing the instruments and event logs is NOT affected by panel lock.
Stop mode is activated by pressing the button.
In Stop mode , the module removes S2 from load (if necessary) and removes the start signal
given to the generator controller (if S2 is configured as a generator and it is running).
If S2 is configured as a generator and it does not stop after the cooling down time, the Fail To Stop
alarm is activated (subject to if the Fail To Stop timer is enabled and its duration). To detect the
generator (S2) is at rest the following must occur:
• S2 Frequency must be zero
• S2 Voltage must be zero
Any latched alarms that have been cleared are reset when Stop mode is entered.
S2 is not placed on load (or started if configured as a generator) when in Stop mode . If remote
start signals are given, the input is ignored until Auto mode is entered.
