DSE 335 - 6.2 ADJUSTABLE PARAMETERS; Scheduler Bank 1

Front Panel Configuration
057-233 ISSUE: 1 Page 80 of 90
NOTE: Refer to DSE335 Configuration Suite Manual (DSE part 057-237) for further details
on configuring, monitoring and control.
Section Parameter As Shown On Display Values
Scheduler
Bank 1
Scheduler Enable Inactive, Active
Bank 1 Run Mode
Do Not Transfer
Transfer to S1
Transfer to S2
S1 Off Load (When S1 = Gen)
S2 Off Load (When S2 = Gen)
Bank 1 Period Weekly, Monthly
Bank 1 Event 1 Week 1-4
Bank 1 Event 1 Day Monday to Sunday
Bank 1 Event 1 Start Time hh:mm
Bank 1 Event 1 Duration hh:mm
Bank 1 Event 2 Week 1-4
Bank 1 Event 2 Day Monday to Sunday
Bank 1 Event 2 Start Time hh:mm
Bank 1 Event 2 Duration hh:mm
Bank 1 Event 3 Week 1-4
Bank 1 Event 3 Day Monday to Sunday
Bank 1 Event 3 Start Time hh:mm
Bank 1 Event 3 Duration hh:mm
Bank 1 Event 4 Week 1-4
Bank 1 Event 4 Day Monday to Sunday
Bank 1 Event 4 Start Time hh:mm
Bank 1 Event 4 Duration hh:mm
Bank 1 Event 5 Week 1-4
Bank 1 Event 5 Day Monday to Sunday
Bank 1 Event 5 Start Time hh:mm
Bank 1 Event 5 Duration hh:mm
Bank 1 Event 6 Week 1-4
Bank 1 Event 6 Day Monday to Sunday
Bank 1 Event 6 Start Time hh:mm
Bank 1 Event 6 Duration hh:mm
Bank 1 Event 7 Week 1-4
Bank 1 Event 7 Day Monday to Sunday
Bank 1 Event 7 Start Time hh:mm
Bank 1 Event 7 Duration hh:mm
Bank 1 Event 8 Week 1-4
Bank 1 Event 8 Day Monday to Sunday
Bank 1 Event 8 Start Time hh:mm
Bank 1 Event 8 Duration hh:mm
Parameters continue overleaf...
