Engine rpm indication
The rev counter scale is displayed in mode (A) in
Track Info Mode and is displayed in mode (B) in Road
Info Mode. To set the Info Mode, see page 187.
The engine rpm is displayed using a rev counter
featuring a coloured wake (C): grey in DAY mode and
white in NIGHT mode
The red wake flashes when the limiter kicks in and
the 15 Over-rev warning light turns on.
The gear is indicated by the switching-on of the
relevant warning light (12, Fig 58).
If the number of rpm is lower than 1,000 RPM, the
wake is not displayed.
During the first 1000 km (620 mi) of the odometer
(vehicle break-in period), or up to the first service, a
engine rpm limiter is set.
the break-in period or the first inspection,
the limiter indicates and advises the rider to
ride at lower revs when the engine is cold.
The limiter threshold changes according to
the engine temperature.
the first inspection, the temperature
thresholds become two:
●
If the engine temperature is below 50° C (122°
F), the rpm threshold is 8000 rpm
0
11:34
A.M.
SPORT
RPM X 1000
Gear
km/h
N
DWC 3
DTC 3
DSC 2
SETTING MENU
TRIP 1
TOT km
1245
137.4 km
LO HI
Lap Off
Gear
11:34
A.M.
STREET
RPM X 1000
km/h
DWC 3
DTC 3
DSC 2
SETTING MENU
TRIP 1
TOT km
1245
137.4 km
LO HI
N
0
190
01‘35.27
11:34
A.M.
SPORT
Lap 1
RPM X 1000
Gear
km/h
5
DWC 3
DTC 3
DSC 2
SETTING MENU
TRIP 1
TOT km
1245
137.4 km
LO HI
C
A
B
Fig 64
107
