Front fork adjustment
The motorcycle fork is completely adjustable.
Fork rebound and compression are adjusted through
electric impulses with Öhlins EC 2.0 controlled
semi-active mode sent by the instrument panel to
the adjusters inside the fork legs.
Spring preload: 9 mm (0.35 in).
Have the preload adjusted at a Ducati Dealer or
authorised Service Centre.
Fig 32
57
