Maintaining the charge
The electric system of this motorcycle is
designed so as to ensure there is a very low power
drain when the motorcycle is OFF. the
features a self-discharge rate that is
normal and depends on ambient conditions as well
as on "non-use" time.
If is not kept at a minimum charge level by
the charger / charge maintainer,
could get damaged if voltage drops under 8 V.
Connector (1) is located under the rider seat (2), on
the side.
To reach it, remove the two screws (3) on both sides
and remove the rider seat (2).
Use only the Ducati-approved charger
(A) for lithium also as a maintainer.
Do not use the charge maintainer kit no.
69924601A (various countries) or charge
maintainer kit no. 69924601AX (for Japan, China and
Australia only), as it is specific for lead
Connect the maintainer to the diagnostics socket (1).
Fig 26
Fig 27
49
