Warning displaying
The instrument panel manages a number of
warnings and alarms, aimed at giving useful
information to the rider during use.
If Track or Road Info Mode was set, if there are any
active warnings, the instrument panel will display
the messages for all the present warnings or alarms:
in a large size (A) for the first 3 seconds and then in a
smaller size (B).
When several warnings or alarms are active, they are
displayed in a sequence, one every 3 seconds.
0
11:34
A.M.
SPORT
RPM X 1000
Gear
km/h
N
DWC 3
DTC 3
DSC 2
LO HI
Lap Off
ICE
0
11:34
A.M.
SPORT
RPM X 1000
Gear
km/h
N
DWC 3
DTC 3
DSC 2
SETTING MENU
TRIP 1
TOT km
1245
137.4 km
LO HI
Lap Off
A
B
Fig 169
230
