Check and set tyre pressure when tyres are
cold. To avoid front wheel rim when riding
on bumpy roads, increase tyre pressure by 0.2 ÷ 0.3
bar (2.90÷4.35 psi).
Front
Pirelli Diablo Supercorsa SP "tubeless" radial type.
Size: 120/70 ZR17.
Rear
Pirelli Diablo Supercorsa SP "tubeless" radial type.
Size: 200/60 ZR17.
Suspension
Front
Öhlins NIX30 upside-down fork with TiN coating of
fork legs, completely adjustable.
Electronic compression and rebound damping
adjustment with Öhlins EC 2.0 controlled
semi-active mode.
Stanchion diameter: 43 mm (1.69 in).
Wheel travel: 125 mm (4.92 in).
Rear
Öhlins TTX36 fully electronically adjustable
monoshock Electronics.
Electronic compression and rebound damping
adjustment with Öhlins EC 2.0 controlled
semi-active mode.
Wheel travel: 130 mm (5.12 in)
Stroke: 65 mm (2.56 in)
Aluminium single-sided swinging arm
Steering damper
Electronically adjustable Öhlins steering damper.
Every is identified by a "click": set to
maximum 14 clicks from the fully open position.
Beyond such adjustment the steering could be
too damped leading to dangerous situations.
Exhaust system
Layout: the exhaust system structure is 4–2–1–2.
Four Lambda sensors and two catalytic
Available colours
Rims: black.
Frame: grey.
285
