Seat lock
Opening
the key into the seat lock (1) and turn it until
the passenger seat (2) catch disengages with an
audible click.
Pull the passenger seat (2) towards the front end of
the motorcycle until releasing it.
Closing
the passenger seat (2) from the side and push
it towards the rear end of the motorcycle until fully
home.
To close the seat cover it from the
motorcycle side and slide it towards the rear side
until hearing the engagement click.
Fig 23
Fig 24
47
