FLEXIBLE BATCH BROILER
EQUIPMENT
MANUAL
April 1, 2007
C-3. Weekly Cleaning (cont’d)
Remove discharge panel and scraper
as was performed for daily cleaning.
Lift rear of burner out of saddle and
continue to hold it.
Remove burner shield.
Pull burner off of orifice and through
broiler wall. Remove from chamber.
Clean, empty any remaining wa
the burner and replace. Thoroughly
dry out all burner ports!
Orifice
