C-3. Weekly Cleaning (cont’d)
Lift flame arrestor up to disengage tabs
from slots. Tabs are located under the
front of the arrestor
Pull flame arrestor out. Clean and
reinstall.
TAB ON THE BOTTOM OF THE
FLAME ARRESTOR DROPS INTO
SLOT
