2009 DURATECH TUB GRINDER OPERATING INSTRUCTIONS
Supplement Section 2: Shut-Down Procedure (For S.N. up to 064)
1. Run 2009EL Electric Tub Grinder until discharge conveyor is empty, and grind as much of the material
in the tub as possible.
2. Push stop button. For the rotor motor the button is located on the control panel marked ‘ROTOR’, and
on the large soft start panel.
Stop button ROTOR
Large soft start panel
stop button
( REV. 02-11 )
3. Then press the stop button for the electrical motor that runs the hydraulic pump. This can also be found in
two different places, on the control panel marked ‘HYDRAULICS’ or on the smaller soft start panel for
the 75 Hp motor.
Stop button HYDRAULICS
Small soft start panel
stop button
Emergency stop
‘EMERGENCY STOP’ shuts off both motors at the same time. Only use if it is an emergency.
