2009 DURATECH TUB GRINDER OPERATING INSTRUCTIONS
tub cover
(Ref # 19)
tub cover
(Ref # 19)
gure 5.8
optional tub cover
lubrication points
(Ref #19)
5.4 Pressure roller lubrication
The grinder has a pressure roller with tapered roller
bearings. These bearings should be checked for lubrication
every 1000 hours of operation or annually‑ whichever
comes rst. These bearings should be checked for proper
adjustment daily.
Tub Pressure Roller
lubrication point
( Ref # 17)
roller chains
lubrication point
( Ref # 5)
( REV. 08-04 )
