2009 DURATECH TUB GRINDER OPERATING INSTRUCTIONS

gure 5.7

radiator pivot

lubrication points

radiator pivots

(Ref # 18)

gure 5.6

tub pivot lubrication

points

tub pivots

(Ref # 12)
