2009 DURATECH TUB GRINDER OPERATING INSTRUCTIONS
5.12 Dodge Rotor bearing installation (SN 065 & up)
WARNING: To ensure the rotor is not unexpectedly started, turn off and lock out or tag the power
sources before proceeding. Failure to observe these precautions could result in bodily injury.
NOTE: Bearing housing caps and bases are not interchangeable and must be matched with mating
half. Install the non‑expansion bearing rst.
Instruction Manual For IMPERIAL Adapter Mounted DODGE ISAF
Pillow Blocks and IP Unitized SphericalRoller Bearing Pillow Blocks, Flanges, Piloted Flanges & Take Ups
GENERAL INFORMATION
WARNING: To ensure that drive is not unexpectedly started, turn off and lock out or tog power source
before proceeding. Failure to observe these precautions could result in bodily Injury.
INSPECTION
Inspect shaft Ensure that the shaft is smooth, straight, clean, and within commercial tolerance Inspect unit. Do not
allow unit to be exposed to any dirt or moisture.
Keep weight off bearing during mounting via a sling or jacks
WARNING: Because of the possible danger to persons(s) or property from accidents which may result
from the improper use of products, it is important that correct procedures be followed. Products must
be used in accordance with the engineering information specied in the catalog. Proper installation,
maintenance and operation procedures must be observed. The instructions in the instruction manuals
must be followed. Inspections should be made as necessary to assure safe operation under prevailing
conditions. Proper guards and other suitable safety devices or procedures as may be desirable or as
may be specied in safety codes should be provided. and are neither provided by Baldor Electric nor
are the responsibility of Baldor Electric. This Unit and its associated equipment must be installed, ad-
justed and maintained by qualied personnel who are familiar with the construction and operation of
all equipment in the system and the potential hazards involved.
DODGE ISAF and IP Spherical Roller Bearing mounted units incorporate a unique way of seating, mounting, and
dismounting the unit to and from the shaft. The patented sealing system (Pat. #5,908,249) has proven effective in
protecting the internal bearing components, due to its constant pressure, while suit allowing a full + or 1 degree of
misalignment.. The patented IMPERIAL system (Pat. #5,489.156) pulls the bearing on the adapter based upon a
predetermined clockwise rotation of the locknut. Dismounting is accomplished via counterclockwise rotation of the
locknut Keep in mind that the thread on the locknut as well as on the adapter is a left hand thread.
( REV. 09-17 )
