2009 DURATECH TUB GRINDER OPERATING INSTRUCTIONS
Supplement Section 1: Start up (For SN 065 and up)
At start up it is recommended that the rotor motor (labeled ‘ROTOR’) be started rst and then the hydraulics motor
(labeled ‘HYDRAULICS’). This will keep the amount of electricity used at initial startup down.
1. Before starting the 2009EL Electric Tub Grinder make sure that “SS bypass” is set to “SS”.
2. Shout the word “Clear”
SS Bypass switch
Note: Bypass is to be used only if starter fails. Leave bypass “off” for normal operations. This allows
starting if the soft starter fails. This is a DIRECT LINE START! Current will be about 700% of full
load amps.
Note: Next step will bring grinder up to full operating RPM.
( REV. 09-17 )
