2009 DURATECH TUB GRINDER OPERATING INSTRUCTIONS
The Teco-Whitewestinghouse Motor that powers the hydraulic pump requires the use of Esso Polyrex Em or
equivalent grease. The (2) grease zerks on this motor must be re‑lubricated every 2000 hours. 130 grams of grease is
to be placed in the drive end zerk. 65 grams required for end opposite the drive. DO NOT OVER GREASE!
Locations of the grease zerks are shown below:
Drive end location (top of motor)Front location (top of motor)
zerk
zerk
Supplement Section 4: Raising/lowering the tub platform, raising/lowering the
discharge conveyor, and folding/unfolding the discharge conveyor.
A 75Hp electric motor powers a hydraulic pump which provides hydraulic oil to raise/lower the tub platform, raise/
lower the discharge conveyor, and fold/unfold the discharge conveyor, tub forward/reverse and conveyor forward.
( REV. 02-11 )
