2009 DURATECH TUB GRINDER OPERATING INSTRUCTIONS
To raise the tub, perform the following steps:
1. Verify that the tub grinder is parked on level surface.
2. Disengage the clutch, and wait for the rotor to stop turning.
3. If your machine is equipped with a tub cover place tub cover in fully closed position
4. As material in the tub may roll some distance, make sure the area on the right hand side of machine is
clear of personnel and equipment. Shout the word “CLEAR”.
5. The engine speed should be at low idle.
6. Operate the tub tilt switch on the control panel to raise the tub. If the red rotor status light on the operator
station control panel is lit, the tub will not raise. If the green rotor status light on the operator station
control panel is lit, the tub may be raised.
7. Raise the tub fully, and install the safety stop on the hydraulic cylinder. The safety stop is located in its
storage location on the inside of frame rail.
NOTE: The tub will not lift if the rotor is turning. Also, when the tub is raised, the clutch will not
engage If the tub is full of material, the hydraulic cylinder will not raise the tub.
Safety stop in stored position
Safety stop in place on hydraulic
cylinder
