2009 DURATECH TUB GRINDER OPERATING INSTRUCTIONS
1. Stop the engine. Turn the battery disconnect switch to the OFF position.
2. Disconnect the negative battery cable from the battery.
3. Disconnect the connectors from the computerized equipment listed on the previous page. Move each har-
ness to a position that will not allow the harness to accidentally move back and make contact with any of
the connector pins.
4. Connect the welding ground cable directly to the part that will be welded. Place the ground cable as close
as possible to the weld in order to reduce the possibility of welding current damage to the bearings, hy-
draulic components, electrical components, and ground straps.
NOTE: If the electrical/electronic components are used as a ground for the welder, or
electrical/electronic components are located between the welder ground and the weld, current ow
from the welder could damage the components.
5. Protect the wiring harness from welding debris and spatter.
6. Use standard techniques to weld the materials.
NEED NEW PICTURE
electronic governor
