4.5 ELECTRICAL
Timing Progressive scanned, non-interlaced
Power Supply Voltages &
Current requirements
± 15 V DC each @ 250 mA steady state
+ 5 V DC @ 250 mA steady state.
Clock Rate 18 Mhz derived from internal crystal oscillator
4.6 MECHANICAL FOR STANDARD
LVDS/FIREWIRE/CAMERALINK CAMERAS
Weight (without lens) 12 ozs. (340 grams)
Temperature limits (operating)
-10°C to 50°C
Temperature limits (storage)
-30°C to 70°C
Dimensions 3.25” (H) X 3.25” (W) X 1.73” (L)
Lens mount Industry standard C- mount
Camera mount 2 X ¼ - 20 threaded holes for top/bottom mount
Digital Video Connector
LVDS:DB-44, female connector (See Appendix C)
FireWire: Standard 1394A connector
CameraLink: Standard 26-pim connector
Power Supply Connector
LVDS: DB-9, Male connector (see Appendix C)
Firewire: Standard 1394A connector
4.7 MECHANICAL FOR COOLED CAMERAS
Weight (without lens) 27.9 ounces (792 grams)
Temperature limits (operating) -10°C to 50°C
Temperature limits (storage) -30°C to 70°C
Dimensions 3.90" (H) X 3.90" (W) X 2.80" (L)
Lens mount Industry Standard C-Mount
Camera mount 4 X ¼ - 20 threaded holes for top/bottom mount
Digital Video Connector
LVDS:DB-44, female connector (See Appendix C)
Firewire: Standard 1394A connector
CameraLink: Standard 26-pim connector
Power Supply Connector
LVDS: DB-9, Male connector (see Appendix C)
Firewire: Standard 1394A connector
4.8 MECHANICAL FOR INTENSICAM
Weight (without lens) 22.0 ounces (624 grams)
Temperature limits (operating) -10°C to 50°C
Temperature limits (storage) -30°C to 70°C
Dimensions 3.25” (H) X 3.25” (W) X 3.20” (L)
Lens mount Industry Standard C-Mount
Camera mount 2 X ¼ - 20 threaded holes for top/bottom mount
Digital Video Connector DB-44, female connector (See Appendix C)
Power Supply Connector DB-9, Male connector (see Appendix C)
NOTE: See Appendix A for dimensioned mechanical diagrams.
