DVC DVC-1412 - Figure 11.1-6: 1412-Multispectral Wheel Non-Cooled Camera (LVDS Shown)

3.26
1.625
4.47
Optical
Center
1" x 32 tpi
C lens mount
1.99
3.25
1.22
0.69 .062
To Focal Plane
16.17
.636
17.48
.69
17.48
.69
1/4 x 20 Thread Mount
M4 Thread Mount
DB44 Female
LVDS Connector
DB9 Male
Power Connector
Auxiliary
Connector
A
B
C
D
DVC Company
SCALE
SIZE
CAD FILE:
DWG. NO.
A
SHEET 1 O F 1
DATE
APPROVALS
DRAWN
CHECKED
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
FRAC TI ONS DEC IMALS ANGL ES
.XX +/- .01
.XXX +/- .005
MATERI AL
FINIS H
DO NOT SCALE DRAWING
1
2
3456
7
8
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF DVC Co. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF DVC Co. IS PROHIBITED.
Filter Wheel Camera
A
B
C
D
12
3
4
567
8
Notes:
10200 Hwy 290 West, Austin, TX 78736
10-0144-01
BVP
Figure 11.1-6: 1412-Multispectral Wheel Non-Cooled Camera (LVDS shown)
61
