DVC DVC-1412 - Figure 11.1-7: 1412-Multispectral Wheel Cooled Camera (Firewire Shown)

3.90
4.79
Optical Center
1" x 32 tpi
C lens mount
2.85
1.46
1/4 x 20 Thread Mount
0.69 0.062
To Focal Plane
3.251.21
3.25
DB9 Male
Power Connector
Auxiliary Connector
Firewire Connector
A
B
C
D
DVC Company
SCALE
SIZE
CAD FILE:
DWG. NO.
A
SHEET 1 OF 1
DATE
APPROVALS
DRA WN
CHECKED
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
FRACTIONS DECIMALS ANGLES
.XX + /- .01
.XXX +/- .005
MATERIAL
FINISH
DO NOT SCALE DRAWING
1
2
3
456
7
8
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF DVC Co. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF DVC Co . IS PROHIBITED.
Cooled Filter Camera
A
B
C
D
12
3
4
567
8
Notes:
10200 Hwy 290 West, Austin, TX 78736
10-0143-01
BVP
Figure 11.1-7: 1412-Multispectral Wheel Cooled Camera (FireWire shown)
