DVC DVC-1412 - Figure 11.1-4: 1412 te Cooler Camera (LVDS Model Shown)

3.90
3.90
1" x 32 thread
C Lens Mount
Optical Center
2.80
1.42
1/4 x 20 Thread Mount
(4 sides)
(nom inal)
(nom inal)
.25
3.25
0.69 +0.12/-0.04
To Focal Plane
(nom inal)
DB44 I/O
Connector
DB9 Male
Power Connector
A
B
C
D
DVC Company
SCALE
SIZE
CAD FILE:
DWG. NO.
A
SHEET 1 OF 1
DATE
AP PR OV ALS
DRAWN
CHECKED
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
FRACTIONS DECIMALS ANGLES
.XX +/- .01
.XXX +/- .005
MATERIAL
FINISH
DO NOT SCALE DRAWING
1
2
3
456
7
8
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF DVC Co. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF DVC Co. IS PROHIBITED.
TE Cooler Camera Assy.
A
B
C
D
12
3
4
567
8
Notes:
10200 Hwy 290 West, Austin, TX 78736
Figure 11.1-4: 1412 TE Cooler Camera (LVDS model shown)
