Cable Assembly and Camera Link Pinouts*
*Cable assembly compatible with both Camera Link configurations
Medium and Full Configurations Base Configuration
Two Channel Link Chips One Channel Link Chip + Camera Control + Serial
Communication
Camera
Connector
Right Angle
Frame
Grabber
Channel Link
Signal
Cable Name
(Reference only)
Camera
Connector
Right Angle
Frame
Grabber
Channel Link
Signal
1 1 inner shield inner shield 1 1 inner shield
14 14 inner shield inner shield 14 14 inner shield
2 25 Y0- Pair 1- 2 25 X0-
15 12 Y0+ Pair 1+ 15 12 X0+
3 24 Y1- Pair 2- 3 24 X1-
16 11 Y1+ Pair 2+ 16 11 X1+
4 23 Y2- Pair 3- 4 23 X2-
17 10 Y2+ Pair 3+ 17 10 X2+
5 22 Yclk- Pair 4- 5 22 Xclk-
18 9 Yclk+ Pair 4+ 18 9 Xclk+
6 21 Y3- Pair 5- 6 21 X3-
19 8 Y3+ Pair 5+ 19 8 X3+
7 20 100 ohm Pair 6+ 7 20 SerTC+
20 7 terminated Pair 6- 20 7 SerTC-
8 19 Z0- Pair 7- 8 19 SerTFG-
21 6 Z0+ Pair 7+ 21 6 SerTFG+
9 18 Z1- Pair 8- 9 18 CC1-
22 5 Z1+ Pair 8+ 22 5 CC1+
10 17 Z2- Pair 9+ 10 17 CC2+
23 4 Z2+ Pair 9- 23 4 CC2-
11 16 Zclk- Pair 10- 11 16 CC3-
24 3 Zclk+ Pair 10+ 24 3 CC3+
12 15 Z3- Pair 11+ 12 15 CC4+
25 2 Z3+ Pair 11- 25 2 CC4-
13 13 inner shield inner shield 13 13 inner shield
26 26 inner shield inner shield 26 26 inner shield
Notes:
1. All pairs are individually shielded with aluminum foil.
2. Pair shields are wrapped aluminum out and are in contact with four internal drains (logic ground).
3. Outer braid and foil (chassis ground) are isolated from inner drains (logic ground).
64
Figure 11.2-2: CameraLink cable
