Pin no. Signal Pin no. Signal Pin no. Signal

16 PIXCLK-

1 PIXCLK+ 31 ENL+

17 GND

2 GND 32 ENL-

18 ENF-

3 ENF+ 33 Not used

19 MSB-

4 MSB+ 34 INPUT1+

20 (MSB-1)-

5 (MSB-1)+ 35 INPUT1-

21 (MSB-2)-

6 (MSB-2)+ 36 R1 IN

22 (MSB-3)-

7 (MSB-3)+ 37 T1 OUT

23 (MSB-4)-

8 (MSB-4)+ 38 COM GND

24 (MSB-5)-

9 (MSB-5)+ 39 VRST_INT

25 (MSB-6)-

10 (MSB-6)+ 40 Reserved

26 (MSB-7)-

11 (MSB-7)+ 41 GND

27 (MSB-8)-

12 (MSB-8)+ 42 Reserved

28 (MSB-9)-

13 (MSB-9)+ 43 GND

29 (MSB-10)-

14 (MSB-10)+ 44 Reserved

30 (MSB-11)-

15 (MSB-11)+

Table 11.3-3: LVDS Digital video connector pinout
