18 / 84 SM-SG-2 Ev3/25062014
6 INSTRUCTION MANUAL SPIDER
6.1 TILTING OF THE MOWER FOR MAINTENANCE
- Always disconnect battery and remove spark plug caps to prevent any injury
- Turn the wheel transmission housing in the direction which you will be tilting the mower to.
- Always tilt the mower control unit up in order to prevent the oil from leaking to the air filter and carburettor.
- Only tilt the mower for the time necessary for maintenance.
Fig. 19
- Safest method is to use a service stand for SPIDER ILD02
Fig. 20
Transmission housing lid up
