Maintenance Manual (960-949) 1-4
Hardware Overview
■ Memory
LPDDR5 on-board memory (8GB or 16GB, 32GB).
■ VGA Controller
The PC comes in with the following type:
■ The internal graphics controller in Intel Processor (Core i*) is used.
■ SSD
The computer supports M.2 SSD. The following capacities are available.
■ 256GB (PCIe I/F)
■ 512GB (PCIe I/F)
■ 1TB (PCIe I/F)
■ Display
The PC comes in with following type:
■ 14“ 16:10 FHD-TFT Anti-Glare type LCD 1920 X 1200
■ Keyboard
The computer’s keyboard layouts are compatible with a 104/105-key
enhanced keyboard - by pressing some keys in combination, all of the
104/105-key enhanced keyboard functions can be performed on the
computer.
The number of keys available on your keyboard will depend on which
country/region your computer is configured for, with keyboards being
available for numerous languages.
In use there are different types of keys, specifically typewriter keys, function
keys, hot keys, and Windows special keys.
■ Tou ch Pad
The Touch Pad located in the palm rest is used to control the movement of
the on-screen pointer.
■ Battery
The computer has a rechargeable Lithium-Ion main battery pack. A part of
this battery pack is used for RTC battery function.
■ Thunderbolt™ 4/USB Type-C™ port
Two Thunderbolt™ 4/USB Type-C™ ports, which support Thunderbolt™ 4
and USB 3.2 Gen2, are provided on your computer.
■ Universal Serial Bus (USB 3.2 Gen1) port
Core Frequency L3 Cache Size Turbo
Number of
cores/number of
threads
i7-1280P 28W 6+8 vPro 24MB 4.8GHz 14/20
i7-1270P 28W 4+8 vPro 18MB 4.8GHz 8/16
i7-1260P 28W 4+8 18MB 4.7GHz 8/16
i5-1250P 28W 4+8 vPro 12MB 4.4GHz 8/16
i5-1240P 28W 4+8 12MB 4.4GHz 8/16
