Maintenance Manual (960-949) 4-1
Chapter 4
Replacement Procedures
This chapter describes the procedure for removing and replacing the field
replaceable units (FRUs) in the PC. It may not be necessary to remove all
the FRUs in order to replace one. The chart below provides a guide as to
which other FRUs must be removed before a particular FRU can be
removed. The numbers in the chart indicate the relevant section numbers
in this manual.
In all cases when removing an FRU, the battery pack must also be
removed. When repairing an FRU that is the potential cause of a computer
fault, use the chart to determine the order in which FRUs need to be
removed.
Table 4-1 the case for the following example
4.10 Cover Assembly and Base Assembly
Cover 4.21 LCD
Assembly
4.20 Wireless LAN card
4.19 Keyboard
4.18 Power button & Fingerprint sensor
4.17 Speaker
4.16 Click pad
4.15 System board
4.14 Fin
4.13 Fan
4.12 SSD
4.11 Battery pack
4.22 Camera module
