Maintenance Manual (960-949) 1-5
Hardware Overview
Two type-A Universal Serial Bus ports, which comply to the USB 3.2
standard, are provided on your computer.The USB 3.2 port is compliant
with USB 3.2 Gen1 standard and backward compatible with
USB 2.0 devices.
■ HDMI out port
HDMI out port can connect with Type A connector HDMI cable.
■ Memory media slot
This slot lets you insert a micro SD™/SDHC™/SDXC™ memory card.
■ Sound system
The sound system is equipped with the following features:
■ Stereo speakers: No-brand
■ Built-in microphone (Webcam, provided with some models)
■ Headphone/Microphone jack
■ Corresponding to Cortana Premium Voice recognition rate
■ Wireless LAN/Bluetooth, Wireless WAN
As a wireless module, Intel802.11ax supporting also bluetooth function is
mounted.
Some models also support 3G/LTE function as wireless WAN function.
■ Web Camera
Web Camera is a device that allows you to record video or take
photographs with your computer. You can use it for video chatting or video
conferences using a communication tool such as Windows Live
Messenger. The Web Camera equipped on some models can support face
recognition feature for Windows Hello.
■ Sensors and others
■ Finger print sensor: Integrated with Power button (BTO)
■ EC/KBC (Embedded Controller/Keyboard Controller): SMSC ME
C1632
1.2 SSD
1.2.1 M.2 SSD
The computer supports a 256GB, 512GB or 1TB SSD.
The SSD specifications are listed in below.
Table 1-1 M.2 SSD specifications (Phison)
Items
Specifications
G8BC000CJ251 G8BC000CJ511
Width (mm) 22.00 ± 0.15 22.00 ± 0.15
Height mm) 1.35 Max 1.35 Max
