Maintenance Manual (960-949) 1-8
Hardware Overview
Table 1-3 LCD module specifications
1.5 Power Supply
The power supply supplies different voltages to the system board and
performs the following functions:
1. Judges that the DC power supply (AC adaptor) is connected to the
computer.
2. Detects DC output and circuit malfunctions.
3. Controls DC IN/Battery icon.
4. Turns the battery charging system on and off and detects a fully
charged battery.
5. Turns the power supply on and off.
6. Provides more accurate detection of a low battery.
7. Calculates the remaining battery capacity.
8. Controls the transmission of the status signal of the main battery.
The power supply output rating is specified in below.
Item G33C000AX110
Number of
Dots
1920(W) × 1200(H)
Dot pitch
(mm)
0.157(H)×0.157(V)
Active
area (mm)
301.59(W) × 188.49(H)
Outline
(mm)
306.59 x 205w/PWB(H) x 2.1 max(D)
