dynabook Portege X40L-K Series - Fin; Figure 4-9 Installing the Fan

Maintenance Manual (960-949) 4-13
Replacement Procedures
Figure 4-9 Installing the Fan
4.14 Fin
4.14.1 Removing the Fin
To remove the Fin, follow the steps below.
1. Remove the following screws and then the Fin.
LCD harness
CN5390
