Maintenance Manual (960-949) 4-7
Replacement Procedures
Example: B6 ... 6mm BIND screw
Screw color/material
B: Black/Nickel
C: Silver/Non-Hexavalent Chromate
U: Other screws (Unique screws: such as stud, etc.)
4.9 Memory media
4.9.1 Installing the Memory media
To insert memory media, follow the steps as detailed below.
1. Turn the memory media so that the contacts (metal areas) face down.
2. Insert the memory media into the memory media slot on your computer.
3. Press the memory media gently until it clicks into place.
Figure 4-2 Inserting memory media
4.9.2 Removing the Memory media
To remove memory media, follow the steps as detailed below.
1. Open the Safely Remove Hardware and Eject Media icon on the
Windows Taskbar.
2. Select memory media.
3. Push the memory media until you hear a click to partially release it.
4. Grasp the media and remove it.
Insert or remove a Memory media in accordance with any instructions in
each Memory Media manual or the manuals of the computer system you
are using.
1. Memory media slot 2. Memory media
