Maintenance Manual (960-949) 3-14
Tests and Diagnostics
·T-NAME..... Test name
(Test name example)
RAM_01.....Main Memory Test
HDD_01.....Sequential Read Test
HDD_02.....Partial Read Test
HDD_03.....Address Jump Test
HDD_04.....Address uniqueness Test
HDD_05.....Specify Address Test
BAT_01.....Battery Charge Test
·Pass..... Pass count which the error occurred
·Sts..... . Status
(Value)
00FF..... Data compare error (Memory Test/HDD Test)
00E0.....Data Not Found (Memory Test)
0002..... Protocol error (Memory Test/HDD Test)
·Address… Address (Memory Test/HDD Test…Sector No.)
·Write..... ... Write value (Memory Test/HDD Test)
·Read.... ...... Read value (Memory Test/HDD Test/ Battery Charge Test)
To clear the log information, press C. To back to the main menu screen,
press ENTER.
3.13 LCD Gamma correction
To execute the LCD Gamma Correction Utility, select 7 from the test
program menu (Top Menu), press Enter and follow the directions on the
screen.
The following message will appear. Press Y.
* Restart system and Start utility *
* Are you sure? (y/n) *
The PC will restart. Press F12 and select the USB memory as the boot
device. Then the following screen will appear and the correction is done
automatically.
After replacing the system board, be sure to execute this program.
