Maintenance Manual (960-949) 1-11
Hardware Overview
Table 1-7 AC adaptor specifications
1.8 USB Type-C Adapter
To expansion the PC functions, some USB Type-C adapters are prepared.
Table 1-8 lists the USB Type-C adapter specifications.
Table 1-8 USB Type-C adapter specifications
Parameter Specification
USB-C straight
G71C000LR310 (2-pin) G71C000LS310 (3-pin)
Power 65W
Input voltage 100V/240V
Input frequency 50Hz to 60Hz
Input current 1.5 A (100V-240V)
Output voltage 5 ~ 20 V
Output current 3 A (Peak 3.25 A)
Item Specifications
Maker Goodway
Appearance
Specifications USB-C to HDMI/VGA Travel Adapter
Parts code G83C000L2110
Functions USB 3.0 port/HDMI out port/RGB
monitor port/LAN jack/USB Type-C port
(Power Delivery Charging)
