86 of 105
Events number 6 Emergency Stop bit 14-10
40005
Events number 7 Low Coolant Level bit 4-0
Events number 8 Low Coolant Temperature bit 9-5
Events number 9 Low Fuel Level In Tank bit 14-10
40006
Events number 10 Low Fuel Pressure bit 4-0
Events number 11 Emergency Power Supplying Load bit 9-5
Events number 12 Generator Running bit 14-10
40007
Events number 13 Generator Not In Auto Mode bit 4-0
Events number 14 Battery Charger Fault bit 9-5
Events number 15 Battery Voltage Low bit 14-10
40008
Events number 16 Battery Voltage High bit 4-0
Events number 17 Low Battery Voltage During Cranking bit 9-5
Events number 18 Locked Rotor bit 14-10
40009
Events number 19 Common Fault #1 Warning/Shutdown bit 4-0
Events number 20 Common Fault #2 Warning/Shutdown bit 9-5
Events number 21 Reserved bit 14-10
40010
Reserved
2
nd
generation Modbus register support
Basic Modbus Functions
1. CONTROLLER INFORMATION
(Read Only)
40080 GSC400 Front Panel
LED Status
0 = OFF,
1 = ON
R
bit0: Over Crank Failure (red)
bit1: Over Crank Warning (amber)
bit2: High engine temp. failure (red)
bit3: High engine temp. warning (amber)
bit4 : Low oil pressure failure (red)
bit5: Low oil pressure warning (amber)
bit6: Engine over speed failure (red)
bit7 : Engine over speed warning (amber)
bit8 : Low fuel level failure (red)
bit9 : Low fuel level warning (amber)
bit10: Low Battery warning (amber)
bit11: Battery Ok (solid green in OFF
and RUN modes, flashing green in
AUTO mode)
bit12: Not in auto (red)
bit13: Not used
