36 E4D NEVO Version 5.0 10822801.C
Appendix
This section is for people that have not previously been using Buccal/Opposing scanning..The instructions
for scanning have not changed in NEVO.
Scanning Buccal/Opposing
The opposing teeth are scanned to acquire bite information for the proposal. The buccal bite is scanned to
align the preparation model with the opposing model.
Scan Opposing
Many clinical operators scan the Opposing while the patient is being anesthetized.
1. On the Setup tab, select Buccal/Opposing.
2. On the Scan tab, select Scan Opposing.
3. Starting with an occlusal view, scan the occlusal surfaces of the opposing dentition. Include the same
number of teeth as the preparation model. Ensure there is good cusp tip data on both the lingual and buccal
sides.
4. Roll to the buccal and scan the buccal side of the opposing dentition. Include gingival data, do not stop
halfway down the tooth.
Your model should resemble the following:
• Good occlusal data
• Good buccal data
