P.34
WARNING Be careful not to overturn the pump when pushing and
pulling it sideways, because the width of the pump is small
to its height.
CAUTION The neck portion of the casters will vibrate during caster
movement. Be sure to keep your fingers and feet out.
CAUTION Do not step on the pump or place objects on it.
To fix the pump, turn the adjusters to the right to lower them.
Adjust the height of the feet evenly to ensure that the pump base is level.
The difference in height between the two sides of the pump base shall not
exceed 1mm.
The adjustment allowance is approximately 5 mm.
[ NOTE ] If the pump is not leveled, shortage of the lubrication oil supply to the
bearing may be caused.
[ NOTE ] To prevent vibrations and airborne noises, keep horizontal level of
pump with the adjustment feet.
4.1.3 How to stack pumps
(1) Adjust both pumps by adjuster-foot, then stack and fix them at both front and
back side by the fixing bracket. Please refer to Fig.4.2
(2) Please make sure to tighten the fixing bolt enough to fix the bracket.
(3) Please fix a lower pump and the floor.
CAUTION Please do not move the pumps with stacked.
CAUTION Please do not stack three pumps or more.
CAUTION Please fix to a floor firmly.
PM10U
EBARA
CORPORATION
