EBARA EV-S50 - 5.4 Dip Switch

P.67
5.4 Dip Switch
Set the dip switches to select the operating modes as shown in Table 5.4 / 5.5 / 5.6.
Table 5.4 Dip Switch-A Settings
No.
Mode
Off
On
1
Data length
7 bits
8 bits
2
Cooling water &
N2 monitoring
Constant Only during operation
3
Buzzer
Not used
Used
4
Operation switched to
Remote
According to signal PUMP STOP
5
-------
-------
-------
6
-------
-------
-------
7
Dil N2 mode
Standard mode
Dil N2-0 mode
8
BP start mode
Automatic
Manual
Table 5.5 Dip Switch-B Settings
No.
Mode
Off
On
1
MP Speed control
Not used
Used
2
BP Speed control
Not used
Used
3
-------
-------
-------
4
-------
-------
-------
5
-------
-------
-------
6
Remote Interface (IF)
Exclusive special IF
No use / standard IF
7
-------
-------
-------
8
LCD screen initialize
Carry out initialize
Do not initialize
Table 5.6 Dip Switch-C Settings
No.
Mode
Off
On
1
Outputs the pump N2
warning.
Normal Open Normal Close
2
-------
-------
-------
3
-------
-------
-------
4
-------
-------
-------
5
-------
-------
-------
6
-------
-------
-------
7
-------
-------
-------
8
-------
-------
-------
DIP SW-A. No.1 This switch allows you to select the data length out of 7 or 8
bits for the pump running status monitoring with the RS232C
communication port.
