Menu 4-1-2 - Signal Inputs
This button is used to call up the list of the digital alarm and signal inputs of the system centre. All
important parameters and the status of the inputs are displayed there. Alarm and signal inputs can be added
using the "New entry" button. Already added digital inputs can be selected and configured using the
corresponding screen or deleted again.
The screen contains the following parameters:
Signal input Eingabe Vorgabe
Message text Freely editable message text of the digital input max. 19 characters -
Priority XX Priority of the signal / alarm input 0..99 0
Delay time [Min.] XX Delay time of the signal / alarm in minutes 0..255 1
Quiescent current (low-active) X Alarmissignalledif
-quiescentcurrent=Yes:(signalvoltagenot
present, low-active)
-quiescentcurrent=No:(signalvoltageis
present, high-active)
Y/N Y
Signal input
Module
Module
1)
towhichthemessage/alarmsignal
is connected
SIOX1 ..SIOX4 -
Submodule XX
Submodule
1)
towhichthemessage/alarm
signal is applied; this is ONLY visible if
module=DDC1..DDC4 has been selected
1..4 -
Input XX
Input
1)
to which the message / alarm signal is
applied
1..12 -
Status XX Current status of the input:
OK = light grey, no signalling
Waiting = yellow: signalling, delay time running,
Message = green: no alarm
Alarm = red: signalling, alarm / message has
been tripped
– -
1)
Designationsofthesupportedmodules/inputs:
CI 4x00system centre, internal inputs IN1 / IN2 (terminals A1, A2 / B1, B2)
SIOX11.extensionmodule,inputs1..12
SIOX22.extensionmodule,inputs1..12
SIOX33.extensionmodule,inputs1..12
SIOX44.extensionmodule,inputs1..12
DDC11.GLTDDCmodule1
DDC22.GLTDDCmodule2
DDC33.GLTDDCmodule3
DDC44.GLTDDCmodule4
Note: GLT = building control and. DDC = Digital Direct Control
Only those SIOX modules and GLT PLC modules are provided for selection that have been configured
accordingly in screen 4-1-1! A description of the functions can be found in chapters Digital inputs.
