ECKELMANN Virtus 5 Series - Page 127



Firmware V7.16.x
16.05.2023
127/183
•
•
•
•
•
Menu 4-1-3 - Special Inputs
Thespecialinputsofthesystemcentrearecalledupusingthisbutton.SeechapterSpecial inputs
for details. All important parameters and the status of the inputs are displayed there. The required special inputs
can be selected and configured using the corresponding screen. Special inputs are permanently predefined in
thesystemcentreandcannotbedeletedoradded;itisonlypossibletodeletetheirconfiguration.
The following special inputs are available:
shunt lock,
emergency power supply
sprinkler alarm
store lighting
setpoint toggle

As the configuration for all special inputs is identical, the explanations are provided using the example
ofthe“shuntlock”.

