ECKELMANN Virtus 5 Series User Manual



Firmware V7.16.x
16.05.2023
128/183
The screen contains the following parameters:
Special inputs Eingabe Vorgabe
Message text Shunt lock (predefined designation of the
special input)
- Shunt lock
PriorityXX Priority of the signal / alarm input --, 0..99 0
Delay [sec.] XX Delay time of the signal / alarm in seconds 0..255 1
Quiescent current (low-active) X Alarmissignalledif
-quiescentcurrent=Yes:(signalvoltagenot
present, low-active)
-quiescentcurrent=No:(signalvoltageis
present, high-active)
Y/N N
Signal input
Module
Module
1)
towhichthemessage/alarmsignal
is connected
SIOX1 ..SIOX4 -
Submodule XX
Submodule
1)
towhichthemessage/alarm
signal is applied; this is ONLY visible if
module=DDC1..DDC4 has been selected
1..4 -
Input XX
Input
1)
to which the message / alarm signal is
applied
1..12 -
Status XX Current status of the input:
OK = light grey, no signalling
Waiting = yellow: signalling, delay time running,
Message = green: no alarm
Alarm = red: signalling, alarm / message has
been tripped
- -
1)
Designationsofthesupportedmodules/inputs:
CI 4x00system centre, internal inputs IN1 / IN2 (terminals A1, A2 / B1, B2)
SIOX11.extensionmodule,inputs1..12
SIOX22.extensionmodule,inputs1..12
SIOX33.extensionmodule,inputs1..12
SIOX44.extensionmodule,inputs1..12
DDC11.GLTDDCmodule1
DDC22.GLTDDCmodule2
DDC33.GLTDDCmodule3
DDC44.GLTDDCmodule4
Note: GLT = building control and. DDC = Digital Direct Control
Only those SIOX modules and GLT PLC modules are provided for selection that have been configured
accordingly in screen 4-1-1! A description of the functions can be found in chapter Digitaleingänge.

